Air Cooler Water Defrosting Evaporator for Cold Storage
products description
Our water defrost Air Cooler : W- series air coolers are divided into three series: W-SD, W-SL and W-SJ types, used differently as evaporators in medium temperature, high-temperature, and low-temperature cold storages.
W series water defrost air coolers have compact structure, light weight, easy installation, fast air circulation in the storage, and it can balance storage temperature.
Product Details
The Air Cooler needs to be used with the refrigeration compressor unit. According to the required storage temperature, the corresponding air cooler should be selected.
W-SD product is suitable for cold storage with a storage temperature from -5°C to 5°C ( 23 ~41 °F), and can store fresh foods, vegetables and other items;
W-SL products are suitable for cold storage with a storage temperature from -15 to -25°C, ( 5 ~ -13 °F)suitable for freezing/refrigerated beef, mutton, fish, and seafood.
W-SJ products are suitable for cold storage with a storage temperature of -25°C to -40°C ( -13 ~ -40 °F), and are mainly used For quick-frozen poultry, seafood, dairy products, etc.
Blowing and Mounted Types
Ceiling Mounted

Oblique Side Blow

Standard Side Blow

Double Side Blow
Floor Stand

Standard Top Blow

Vertical Side Blow
Features
Steel Plate Cabinet with plastic spray
Corrosion proof
Color can be customized


Mechanically expanded copper tubes.
Long distance air throw cowl available
Refrigerant: R404A, R507A, R22, etc.


Blue hydrophilic aluminum foil.
More types of AL foil available.
MaEr Fan Motor.
EBM Motor Available.

Model Description

Specification
Standard | ● |
Optional | ○ |
HT-WS-J/D/L Series Water Defrost Air Cooler Model Specification | ||||||||||||||||||
HT-WS | Evaporating Area | Defrost | Temperature | Installation Blow Type | Fan Motor | Fan Type | Fin | |||||||||||
m² | S | D | R | J / D / L | Roof | Floor | Brand | Qty | G | Z | Light Foil | Hydrophilic | Others | |||||
Water | Electric | Hot Fluorine | Low Mid High | Standard | Oblique | Double Side | Standard | Vertical | MaEr | EBM | Outer Rotor | Axial Flow ram | ||||||
30 | ● | ○ | ○ | ● | ● | ○ | ○ | ● | ● | ○ | 2 | ● | ● | ○ | ○ | |||
40 | ● | ○ | ○ | ● | ● | ○ | ○ | ● | ● | ○ | 2/3 | ● | ○ | ● | ○ | ○ | ||
55 | ● | ○ | ○ | ● | ● | ○ | ○ | ● | ● | ○ | 2/3 | ● | ○ | ● | ○ | ○ | ||
60 | ● | ○ | ○ | ● | ● | ○ | ○ | ● | ● | ○ | 2/3 | ● | ○ | ● | ○ | ○ | ||
70 | ● | ○ | ○ | ● | ● | ○ | ○ | ● | ● | ○ | 2/3 | ● | ○ | ○ | ● | ○ | ||
80 | ● | ○ | ○ | ● | ● | ○ | ○ | ● | ● | ○ | 2/3 | ● | ○ | ○ | ● | ○ | ||
85 | ● | ○ | ○ | ● | ● | ○ | ○ | ● | ● | ○ | 3/4 | ● | ○ | ○ | ● | ○ | ||
100 | ● | ○ | ○ | ● | ● | ○ | ○ | ● | ● | ○ | 3/4 | ● | ○ | ○ | ● | ○ | ||
110 | ● | ○ | ○ | ● | ● | ○ | ○ | ● | ● | ○ | 3/4 | ● | ○ | ○ | ● | ○ | ||
120 | ● | ○ | ○ | ● | ● | ○ | ○ | ● | ● | ○ | 4 | ● | ○ | ○ | ● | ○ | ||
140 | ● | ○ | ○ | ● | ● | ○ | ○ | ○ | ● | ● | ○ | 4 | ● | ○ | ○ | ● | ○ | |
160 | ● | ○ | ○ | ● | ● | ○ | ○ | ○ | ● | ● | ○ | 4 | ● | ○ | ○ | ● | ○ | |
185 | ● | ○ | ○ | ● | ● | ○ | ○ | ○ | ● | ● | ○ | 4 | ○ | ● | ○ | ● | ○ | |
200 | ● | ○ | ○ | ● | ● | ○ | ○ | ○ | ● | ● | ○ | 4 | ○ | ● | ○ | ● | ○ | |
250 | ● | ○ | ○ | ● | ● | ○ | ○ | ○ | ● | ● | ○ | 4 | ○ | ● | ○ | ● | ○ | |
260 | ● | ○ | ○ | ● | ● | ○ | ○ | ○ | ● | ● | ○ | 4 | ○ | ● | ○ | ● | ○ | |
300 | ● | ○ | ○ | ● | ● | ○ | ○ | ○ | ● | ● | ○ | 4 | ○ | ● | ○ | ● | ○ | |
330 | ● | ○ | ○ | ● | ● | ○ | ○ | ○ | ● | ● | ○ | 4 | ○ | ● | ○ | ● | ○ | |
350 | ● | ○ | ○ | ● | ● | ○ | ○ | ○ | ● | ● | ○ | 4 | ○ | ● | ○ | ● | ○ | |
390 | ● | ○ | ○ | ● | ● | ○ | ○ | ○ | ● | ● | ○ | 4 | ○ | ● | ○ | ● | ○ | |
400 | ● | ○ | ○ | ● | ● | ○ | ○ | ○ | ● | ● | ○ | 4 | ○ | ● | ○ | ● | ○ | |
410 | ● | ○ | ○ | ● | ● | ○ | ○ | ○ | ● | ● | ○ | 4 | ○ | ● | ○ | ● | ○ | |
480 | ● | ○ | ○ | ● | ● | ○ | ○ | ○ | ● | ● | ○ | 4 | ○ | ● | ○ | ● | ○ | |
500 | ● | ○ | ○ | ● | ● | ○ | ○ | ○ | ● | ● | ○ | 4 | ○ | ● | ○ | ● | ○ | |
520 | ● | ○ | ○ | ● | ● | ○ | ○ | ○ | ● | ● | ○ | 4 | ○ | ● | ○ | ● | ○ | |
600 | ● | ○ | ○ | ● | ● | ○ | ○ | ○ | ● | ● | ○ | 4 | ○ | ● | ○ | ● | ○ | |
670 | ● | ○ | ○ | ● | ● | ○ | ○ | ○ | ● | ● | ○ | 4 | ○ | ● | ○ | ● | ○ | |
For additional configurations not listed, please concult YSHT, thank you! |
More About Electric Defrosting Air Cooler
Water defrost air coolers are an important part of modern cold storage solutions. Its efficient cooling capacity combined with automatic water-based defrost ensures that perishable goods are stored under optimal conditions. With energy-efficient design, advanced temperature control and durability, air cooler units are ideal for a variety of applications, from food and pharmaceutical storage to cold chain logistics and industrial refrigeration. As industries continue to prioritize energy efficiency and product integrity, demand for water-defrost evaporating air cooler units is likely to grow, cementing their role as the cornerstone of contemporary refrigeration solutions. By investing in these evaporating units, businesses can increase operational efficiency while ensuring the safety and quality of their stored products.
Features
1. Energy Efficiency: Water defrost air coolers are designed to minimize energy consumption. Using warm water for defrost is often more energy efficient than electric heating, thus reducing operating costs.
2. AUTO-DEFROST: The automatic defrost feature enables hands-free operation, ensuring the device maintains optimal performance without the need for constant manual intervention.
3. Temperature Control: This unit is equipped with an advanced control system that can accurately adjust the temperature to ensure that the cold storage environment remains stable and within the required range.
4. Durability: Water defrost air coolers are made from high-quality materials and are designed to withstand the harsh conditions commonly found in cold storage facilities, ensuring a long service life.
